To implement FPV Gimbal designs you will need to generally follow this guide: Adding Servo Gimbal to FPV Multirotor.
Medlin Drone offers 3D printing services for gimbal designs. If there is not a design available for your frame, you can commission a new design from Medlin Drone.
If you use these designs, please consider helping support Medlin Drone.
All Designs:
FPV Gimbal – FSQ35 / FlightSquare 3.5 – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:6002860 Design commissioned by: Jae Hyeok Lee
ViewFPV Gimbal – DrewDrones 3″ / 4″ – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5996732 Design commissioned by: DrewDrones
ViewAlta X – Pro FPV Piloting Gimbal (Servo Tilt)
Medlin Drone single-axis “Timing Belt” FPV gimbal designed to mount to a Freefly Alta X. Pre-built Alta X Piloting Gimbal and ‘AIO’ available here! This gimbal improves your ability to navigate complex environments and track subjects, allowing full view above and bellow the craft. It can be controlled via a dial/slider, head tracking, and various other methods. This is the…
ViewFPV Gimbal – FPVframe.ch FlowX V2 – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5820622 Design commissioned by: FPVframe.ch
ViewFPV Gimbal – Geprc Mark 5 (O2) – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5820452 Design commissioned by: Christopher Clark
ViewWhoop FPV Gimbal
This is a FPV Gimbal designed for whoops/micros that mounts to a standard whoop board (26mm x 26mm). Kits and Pre-Builts available at the Medlin Drone Store! Files on Thingiverse: https://www.thingiverse.com/thing:5733796 Long overdue, I have finally made a tiny whoop gimbal to practice and enjoy flying with a FPV gimbal, via head tracking or other means of…
ViewFPV Gimbal – Halo Osiris LONGBODY – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5650412 Design commissioned by: Andrew Lawrence
ViewFPV Gimbal – iFlight Chimera7 Pro – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5593424 Design commissioned by: Anonymous
ViewFPV Gimbal – 30.5 x 30.5 Mounting – LDX-218
This is the base design has a 30.5×30.5 mounting pattern seen on some BQE and Hyperlow frames and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5539339 Design commissioned by: Richard Howarth
ViewFPV Gimbal – CMW BangGod – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5500272 Design commissioned by: Ryan Hall
ViewFPV Gimbal – GEPRC CineLog 35 – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5432361 Design commissioned by: Anonymous
ViewFPV Gimbal – Rotor Riot SkyLite – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5395923
ViewFPV Gimbal – WoodChuckFPV Wasp 5″ HD – LDX-218
This is the base design is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5378724
ViewFPV Gimbal – iFlight Protek35 – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5372832 Design commissioned by: Kevin Fuentes
ViewFPV Gimbal – Team Mistral AK47 HD – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5372831 Design commissioned by: Alain Morla
ViewFPV Gimbal – WON’s Whoop Frame 3-inch – LDX-218
This is the base design is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5353793 Design commissioned by: Hyeong Seob Kim
ViewFPV Gimbal – Rebel Basic – LDX-218
This is the base design is intended to be used with the 18mm Universal Camera Mount. This frame design forced this gimbal to use a 18mm bearing housing meaning it is not compatible with the standard camera mount options shown elsewhere on the site. Guide for 3D printing the gimbal design here. Files on Thingiverse:…
ViewFPV Gimbal – Moka Ayeleon 4″ / Ayeleon 5″ / Moka 3.5″ – LDX-218
This is the base design is intended to be used with the Universal Camera Mount. I have made a ‘vertical servo’ and ‘push through’ base design, I prefer the ‘push though’ but both had advantages/disadvantages. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5332112 Design commissioned by: Mokaframe – Mokaframe.com
ViewFPV Gimbal – Flywoo Mr.Croc – LDX-218
This is the base design will fit any of the Mr.Croc frames and is intended to be used with the Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5274072
ViewFPV Gimbal – Reptile Cloud-149 – LDX-218
This frame design forced this gimbal to use a 18mm bearing housing meaning it is not compatible with the standard camera mount options shown elsewhere on the site. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5244636 **This design is currently untested, but should work, will update once it has been tested**
ViewFPV Gimbal – Ethix CineRat – LDX-218
This is the base design and is intended to be used with the Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5240391 **This design is currently untested, but should work, will update once it has been tested** Design commissioned by: Alejandro Ibanez
ViewFPV Gimbal – iFlight XL5 / XL6 / XL7 / DC5 / SL5 / F5 / F5D – LDX-218
This is the base design and is intended to be used with the Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5186805
ViewFPV Gimbal – QAV-S JohnnyFPV – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5180747
ViewFPV Gimbal – Project 399 Super G / Super G Plus / Super G 10″ – LDX-218
This design has two options, one with the servo in horizontal orientation and one in vertical orientation. Both designs allow very high uptilt at or greater than 45 degrees. This is the base design and is intended to be used with the Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on…
ViewFPV Gimbal – Holybro Kopis CineWhoop 3″ – LDX-218
This design has two options, one with the servo in horizontal orientation and one that conserves space by putting the servo vertical. Both designs will require the rear to be zip tied down to the top plate as there is no standoffs there to bolt to, this is similar to the Shen Drones Squirt design,…
ViewFPV Gimbal – GEPRC Crocodile7 – LDX-218
This design is for the base of the gimbal and is intended to be used with the Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5152279 Design commissioned by: Dominic Herrera If the Universal Mount doesn’t work with this base or for your application this design is compatible with…
ViewFPV Gimbal – Universal Camera Mount
This is a FPV gimbal design that accepts any camera via the standard action camera ‘tab’ mount. This is compatible with all existing kits and tutorials and with almost all of the existing Medlin Drone gimbal designs, mounting on the standard Medlin Drone 20mm bearing housing, and will work with analog, DJI, and Shark Byte,…
ViewDual-Axis FPV Gimbal
I have finally tried building and flying a dual axis FPV gimbal, with camera pitch and roll being dynamically controlled via head tracking. I wanted to know if this would be possible to fly in acro, how difficult it would be to learn, and if it would be practical. I want to briefly discuss what…
ViewFPV Gimbal – ImpulseRC Apex – LDX-218
This is the base design is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5040991
ViewFPV Gimbal – QAV-S / QAV-S JB Edition – LDX-218
This is the base design is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5041010
ViewFPV Gimbal – AOS 5 / 5.5 / 7 / Cine35 – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5040239
ViewFPV Gimbal – Rotor Riot CL1 / HD1 / XR – LDX-218
This is the base design and is intended to be used with the 18mm Universal Camera Mount. It will fit both the normal and XR versions, the base is specific to the CL1 and HD1 as they have different bolt patterns. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:5031319
ViewFPV Gimbal – T-Motor FT5 MKII V2 HD – LDX-218
This is a designfor the T-Motor FT5 MKII V2 HD, I have chosen to reverse the drone and use the back as the front in order to not move the DJI Air Unit, but I am including options for both normal and reverse orientation. Guide for 3D printing the gimbal design here. Files on Thingiverse:…
ViewFPV Gimbal – Camera Mount Options
Many of the open source gimbal designs share the same 20mm bearing housing, this means that for most designs the only frame-specific part is the base, while the top/camera mount is cross-compatible between all designs that share the 20mm bearing housing. This doesn’t mean that they will all work perfectly on any base/frame, this just…
ViewUniversal Head Tracker V2
Prebuilt head trackers available here: https://medlin-drone-store.myshopify.com/products/pre-built-head-tracker This is a case and mount for an Arduino based Open-Source Head Tracker. This is the the version two based off a different design. There are mount designs for both Fat Shark and DJI, as well as a universal mount. Files on Thingiverse: https://www.thingiverse.com/thing:4980301
ViewFPV Gimbal – Shen Drones Terraplane – LDX-218
This is a design for the Shen Drones Terraplane. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:4964713 UPDATE: This design is compatible with the 20mm Universal Mount. If the Universal Mount doesn’t work with this base or for your application this design is compatible with the 20mm GoPro/FPV Camera Mount Options:https://www.thingiverse.com/thing:4983596
View3D Printable Accessories
This post will contain an assortment of accessories related to head tracking gimbals for FPV drones. Servo Wire Bending Jig for 1mm Servo Wire (20, 22, 24, 26, 28, 30, and 32mm): https://www.thingiverse.com/thing:4957904Apex RC Servo Horn Sleeve/Insert for 1mm Servo Wire: https://www.thingiverse.com/thing:4983071Camera Cap for GoPro-specific designs: https://www.thingiverse.com/thing:4957902Gyroflow – Cold Shoe GoPro Tab Mount: https://www.thingiverse.com/thing:5242803
ViewFPV Gimbal – Xilo JB Freestyle – LDX-218
This frame design forced this gimbal to use a 18mm bearing housing meaning it is not compatible with the standard camera mount options shown elsewhere on the site. This is the base design and is intended to be used with the 18mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on…
ViewFPV Gimbal – Diatone Taycan – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:4957897 The following is a link to a text file that contains the dimensions entered into the parametric design:
ViewOn-Servo Design
I have started tinkering with a design where the top “hinge” rotates directly on the servos axle instead of having a secondary axle and linkage. This would provide some advantages if it were able to produce smooth movement but will also have some notable disadvantages, worth testing though. Will update post after initial testing. Update:…
ViewFPV Gimbal – Shen Drones Geyser/Squirt – LDX-218
This is design for the Shen Drones Geyser and Squirt (V1/V2/V3), for the Squirt there are no standoffs that could match the rear screw holes are just zip tied down, this has worked fine and I am yet to break a zip tie despite some hard crashes. Guide for 3D printing the gimbal design here.…
ViewFPV Gimbal – TBS Source One – LDX-218
This is the base design and is intended to be used with the 20mm Universal Camera Mount. Guide for 3D printing the gimbal design here. Files on Thingiverse: https://www.thingiverse.com/thing:4941753 The following is a link to a text file that contains the dimensions entered into the parametric design, this will allow you to modify the design…
ViewFPV Gimbal – Shen Drones Ichabod V2 – LDX-218
This is a design I made for the Ichabod V2. I am including a version that has a built in TBS Crossfire Immortal-T mount, as well as one that doesn’t. This is a specific offshoot design where I removed the bearing housing and separately created a bear housing in a different CAD model. I am…
ViewUniversal Head Tracker V1
This is a case and mount for an Arduino based Open-Source Head Tracker. This is the head tracker enclosure design I started with, the enclosure itself is not my design, Lee from Painless360 designed it, I only made the mount for Fat Shark, its a rudimentary design but works. This can be mounted universally using…
ViewEarly Designs
After some early testing I started to make some changes to the gimbal designs Andy Shin had made, reinforcing the hinge and even experimenting with designs that intentionally added friction to the hinge in addition to a sprung servo linkage in an attempt to stop the servo jitters from making it to the camera. I…
View
