Tutorials

This a page for Medlin Drone tutorials related to Head Tracking Gimbals for FPV Multirotors.

How-To 3D Print a FPV Gimbal

This is a quick run down on how to print the gimbal. TPU, 100% infill, supports enabled, print on the side such that the hinge profile is not sliced by layers, reference the pictures bellow. The Camera Cap can be printed strait up and down with the same settings.

Parametric Design How-To

First you will need to install FreeCAD and download the Parametric Design. Open the design (ParametricServoGimbalxxxxxxxx.FCStd) in FreeCAD. It is recommended to open the design for your specific GoPro and analog/digital combination, as most computers will struggle with the master version that includes all the combinations. Double click the “Spreadsheet” on the center left. SelectContinue reading “Parametric Design How-To”

My Setup and Gear

The head tracker doesn’t add much to the overall system once it’s set up and working, I use the same carrying cases and bag. Your gear doesn’t need to match this to use a head tracking gimbal, the only thing you need is to verify that your transmitter supports a trainer function via an auxiliaryContinue reading “My Setup and Gear”
